2710-36 DIMENSIONS

36 1/8"L × 4 1/8”W × 4 1/8"H

SPECIFY OAH: 24“ / 30” / 36” CANOPY: 32 1/2“L × 4 5/8”W × 1 1/4”H

42 WATT DIMMABLE LED: LTF QUANTUM LUX, 2700K, CRI 90+, 3100 LUMENS

2710-48 DIMENSIONS

48 1/8"L × 4 1/8”W × 4 1/8"H

SPECIFY OAH: 24“ / 30” / 36” CANOPY: 44 1/2“L × 4 5/8”W × 1 1/4”H

56 WATT DIMMABLE LED: LTF QUANTUM LUX, 2700K, CRI 90+, 4150 LUMENS

2710-60 DIMENSIONS

60 1/8"L × 4 1/8”W × 4 1/8"H

SPECIFY OAH: 24“ / 30” / 36” CANOPY: 56 1/2“L × 4 5/8”W × 1 1/4”H

70 WATT DIMMABLE LED: LTF QUANTUM LUX, 2700K, CRI 90+, 5185 LUMENS

CLEAR CAST BAR WITH SIGNATURE DURKIN DESIGN SURFACE TEXTURE

36-
(4) E-12 SOCKET; G16 1/2 BULB
OR LED EQUIVALENT

48-
LTF QUANTUM LUX DIMMABLE LED: 56 WATTS LED, 4150 LUMENS, 2700K, 90+ CRI
DRY RATED INSTALLED

60-
LTF QUANTUM LUX DIMMABLE LED: 70 WATTS LED, 5185 LUMENS, 2700K, 90+ CRI
DRY RATED INSTALLED

DOUGLAS DURKIN
