3108 PORTRAIT

TEARSHEET

  • SINGLE - 1 3/4” H X 16 1/2” W & 11 1/2” PROJECTION

    10 1/4” X 1 3/4” BACKPLATE

    DOUBLE - 33 1/4"W x 1 3/4"H & 11 1/2" PROJECTION

    29 1/4" x 1 3/4" BACKPLATE

  • DIRECT WALL MOUNT

    FULL RANGE DIMMER ON BACKPLATE

    --

    DIRECT WALL MOUNT

    --

    PIN-UP WALL MOUNT

    FULL RANGE DIMMER ON CORD

  • SINGLE -
    (2) E-17 SOCKET; T6-1/2 BULB
    OR LED EQUIVALENT

    DOUBLE-
    (4) E-17 SOCKET; T6-1/2 BULB
    OR LED EQUIVALENT
